• CPU LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core, Pentium® Gold and Celeron® Processors
  (Go to GIGABYTE's website for the latest CPU support list. )
  L3 cache varies with CPU
• Chipset Intel® H610 Express Chipset
• Memory Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules
  2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity)of system memory
  Dual channel memory architecture
  Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate innon-ECC mode)
  Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  Support for Extreme Memory Profile (XMP) memory modules
  (The CPU and memory configuration may affect the supported memory types, datarate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information. )
• Onboard Graphics Integrated Graphics Processor-Intel® HD Graphics support:
  - 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3.
  - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3.
  ** Support for native HDMI 2.1 TMDS compatible ports.
  (Graphics specifications may vary depending on CPU support. )
• Audio Realtek® Audio CODEC
  High Definition Audio
  2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure
  7.1-channel audio, access the audio software for audio settings.
• LAN Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
• Expansion Slots CPU:
  - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
  Chipset:
  - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
  - 1 x M. 2 Socket 1 connector, for the CNVi wireless communication module (M2_WIFI)
• Storage Interface Chipset:
  - 1 x M. 2 connector (Socket 3, M key, type 2280 PCIe 3.0 x4/x2 SSD support)
  - 4 x SATA 6Gb/s connectors
• USB Chipset:
  1 x USB Type-C® port with USB 3.2 Gen 1 support, available through theinternal USB header
  - 3 x USB 3.2 Gen 1 ports (1 ports on the back panel, 2 ports available through the internal USB header)
  - 2 x USB 2.0/1.1 ports available through the internal USB header
  Chipset+1 USB 2.0 Hub:
  - 4 x USB 2.0/1.1 ports on the back panel
• Internal I/O Connectors 1 x 24-pin ATX main power connector
  1 x 8-pin ATX 12V power connector
  1 x CPU fan header
  2 x system fan headers
  1 x M. 2 Socket 3 connector
  4 x SATA 6Gb/s connectors
  1 x front panel header
  1 x front panel audio header
  1 x USB Type-C® header, with USB 3.2 Gen 1 support
  1 x USB 3.2 Gen 1 header
  1 x USB 2.0/1.1 header
  1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
  1 x serial port header
  1 x Clear CMOS jumper
• Back Panel Connectors 1 x DisplayPort
  1 x HDMI port
  1 x USB 3.2 Gen 1 port
  4 x USB 2.0/1.1 ports
  1 x RJ-45 port
  3 x audio jacks
• I/O Controller iTE® I/O Controller Chip
• H/W Monitoring Voltage detection
  Temperature detection
  Fan speed detection
  Water cooling flow rate detection
  Fan fail warning
  Fan speed control * Whether the fan speed control function is supported will depend on the fan you install.
• BIOS 1 x 128 Mbit flash
  Use of licensed AMI UEFI BIOS
  PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
• Unique Features Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
  Support for Q-Flash
• Bundled Software Norton® Internet Security (OEM version)
  LAN bandwidth management software
• Operating System Support for Windows 11 64-bit
  Support for Windows 10 64-bit
• Form Factor Micro ATX Form Factor; 24.4cm x 22.0cm
