Sales Model Name
PM3406CKA-LY0288

EAN Code
4711636194624

UPC Code
199291194625

WEEE
0.96

BASE UNIT
VSNX0971-BU1113

Operating System
Non-preinstalled OS

LCD cover-material
Aluminum

LCD cover-color
Misty Grey

Top case-material
Aluminum

Top case-color
Misty Grey

Bottom case-material
Aluminum

Bottom case-color
Misty Grey

Military grade
US MIL-STD 810H military-grade standard

Panel Size
14.0-inch

Backlit
LED Backlit

Brightness
300nits

Resolution
WUXGA (1920 x 1200) 16:10

Glare
Anti-glare display

Color gamut
NTSC: 45%

View angle(H/V)
178/178

Response time(Typ/Max) (ms)
20/25

Refresh rate
60Hz

Contrast  (Typ)
1000:1

Touch Panel
Non-touch screen

Screen-to-body ratio
86 %

IPS-level
Wide view

Processor
AMD RyzenAI 5 330 Processor 2.0GHz (8MB Cache, up to 4.5 GHz, 4 cores, 8 Threads)
 NPU 50 TOPs

Neural processor
AMD Ryzen AI over 40 TOPs

Chipset
N/A

Discrete/Share
Share

Integrated GPU
AMD Radeon 820M

VRAM
N/A

How to upgrade memory
Upgradable
 Need to remove bottom/top case

Expansion Slot(includes used)
2x DDR5 SO-DIMM slots
1x M. 2 2230 PCIe 4.0x4
1x M. 2 2280 PCIe 4.0x4

DIMM Memory
16GB DDR5 SO-DIMM

Total System Memory
DDR5 16GB

Storage
512GB M. 2 2280 NVMe PCIe® 4.0 SSD

Front-facing camera
1080p FHD camera
With privacy shutter

Wireless
Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5.4 Wireless Card

NumberPad
N/A

FingerPrint
FingerPrint

Keyboard type
Backlit Chiclet Keyboard

I/O ports
2x USB 3.2 Gen 1 Type-A
2x USB 3.2 Gen 2 Type-C support display / power delivery
1x HDMI 2.1 TMDS
1x 3.5mm Combo Audio Jack
1x RJ45 Gigabit Ethernet

Audio
Audio by Dirac
Smart Amp Technology
Built-in speaker
Built-in array microphone

Battery
70WHrs, 4S1P, 4-cell Li-ion

AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal

Required charging power
Min: 55W
Max: 65W
*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher.

Dimension (WxHxD)
31.27 x 22.71 x 1.79 ~ 1.80 cm (12.31" x 8.94" x 0.70" ~ 0.71")

Weight (with Battery)
1.48 kg (3.26 lbs)

Weight (w/o Battery)
1.22 kg (2.69 lbs)

Security
Fingerprint sensor integrated with Power Key
Kensington Nano Security Slot(6x 2.5mm)
BIOS Integrity Measurement Support
BIOS Self Recovery
Microsoft Secured-core PC
Microsoft Security Level 3
Support Absolute Persistence 2.0 (Computrace)
Trusted Platform Module (TPM) 2.0
N/A

MyASUS feature
System diagnosis
Battery health charging
Fan Profile
Splendid
Function key lock
WiFi SmartConnect
AppDeals
Link to MyASUS

Built-in Apps
MyASUS
AI ExpertMeet (AI features need devices with 12GB RAM or more)

Disclaimer for Built-in Apps
Built-in Apps vary from OS SKU.

*MyASUS/McAfee don't support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)

Reparability Index (for France)
9.9

Reparability Index (for Belgium)
