Part No
90NX0731-M01J40

Sales Model Name
B3604CMA-Q91225

EAN Code
4711387953198

UPC Code
197105953192

WEEE
1.547

BASE UNIT
VSNX0731-BUA114

Operating System
Non-preinstalled OS

Office


LCD cover-material
Aluminum

LCD cover-color
Star Black

Top case-material
Plastic

Top case-color
Star Black

Bottom case-material
Plastic

Bottom case-color
Black

Military grade
US MIL-STD 810H military-grade standard

Panel Size
16.0-inch

Backlit
LED Backlit

Brightness
300nits

Resolution
WUXGA (1920 x 1200) 16:10

Glare
Anti-glare display

Color gamut
NTSC: 45%

View angle(H/V)
178/178

Response time(Typ/Max) (ms)
11/9

Refresh rate
60Hz

Contrast  (Typ)
1000:1

Touch Panel
Non-touch screen

Screen-to-body ratio
85 %

IPS-level
Wide view

Processor
Intel® Core Ultra 7 Processor 155H 1.4 GHz (24MB Cache, up to 4.8 GHz, 16 Cores) Intel® AI Boost NPU

Neural processor
Intel® AI Boost NPU

Chipset
N/A

Discrete/Share
Share

Integrated GPU
Intel® Graphics

VRAM
N/A

How to upgrade memory
Upgradable Need to remove bottom/top case

Expansion Slot(includes used)
2x DDR5 SO-DIMM slots1x M. 2 2230 PCIe 4.0x41x M. 2 2280 PCIe 4.0x4

DIMM Memory
16GB DDR5 SO-DIMM

Total System Memory
DDR5 16GB

Storage
512GB M. 2 2280 NVMe PCIe® 4.0 SSDSSD Housing for storage expansion

Front-facing camera
720p HD cameraWith privacy shutter

Wireless
Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth® 5.3 Wireless Card

NumberPad
N/A

FingerPrint
FingerPrint

Keyboard type
Backlit Chiclet Keyboard

I/O ports
2x USB 3.2 Gen 2 Type-A2x Thunderbolt 4, compliant with USB4, supports display / power delivery1x HDMI 2.1 TMDS1x 3.5mm Combo Audio Jack1x RJ45 Gigabit Ethernet

Audio
Audio by DiracBuilt-in speakerBuilt-in array microphone

Battery
50WHrs, 3S1P, 3-cell Li-ion

AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal

Dimension (WxHxD)
35.80 x 25.43 x 2.03 ~ 2.03 cm (14.09" x 10.01" x 0.80" ~ 0.80")

Weight (with Battery)
1.90 kg (4.19 lbs)

Weight (w/o Battery)
1.71 kg (3.77 lbs)

Security
Fingerprint sensor integrated with Power KeyKensington Nano Security Slot(6x 2.5mm)BIOS Booting User Password ProtectionBIOS setup user passwordHDD User Password Protection and SecuritySupport Absolute Persistence 2.0 (Computrace)Trusted Platform Module (TPM) 2.0N/A

Antivirus


MyASUS feature
System diagnosisBattery health chargingFan ProfileSplendidTru2LifeFunction key lockWiFi SmartConnectAppDealsLink to MyASUS

Built-in Apps
MyASUS

Disclaimer for Built-in Apps
Built-in Apps vary from OS SKU. *MyASUS/McAfee don"t support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)

Reparability Index (for France)
9.5

Ecolabels & Compliances
EPEAT GoldEnergy star 8.0FSC MixREACHRoHSTCO Certified

Base Warranty
3Y Pick up/ return

Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgradeACX13-007023NX//2Y Extension 5Y OnSite Service(Next Business Day)*upgradeACX14-017300NX//3Y HDD Retention*upgrade*If you would like to know the details, please contact your sales teams.

Battery warranty
Commercial NB B series Battery warranty follow system warranty, 4Y-5Y by WEP option.

Sustainable Material_Top cover(A part)
50% PIR recycled aluminum

Sustainable Material_Keyboard frame (C part)
30% PCR recycled plastic(cover or inner frame)

Sustainable Material_Bottom cover (D part)
35% PCR recycled plastic(cover or inner frame)

Sustainable Material_Battery


Sustainable Material_Keyboard
50% PCR recycled plastic cap

Sustainable Material_Speaker
45% PCR + 5% OBP PCR recycled plastic enclosure

Sustainable Material_Total PCR recycled plastic
30.8%

Így is ismerheti: ExpertBook B 3 B 3604 CMA Q 91225, ExpertBookB3B3604CMAQ91225, ExpertBook B3 B3604CMA Q91225, ExpertBookB3B3604CMA-Q91225, ExpertBook B3 B3604CMA-Q 91225
