• Model Name:

  LGS310MPC


• Routing:

  Static Routing, IPv4 (63 max entries), IPv6 (21 max entries)


• Ports:



  • 8 Gigabit Ethernet


  • 2 Gigabit SFP






• Memory:

  256MB


• LEDs:

  Power, Fault, PoE Max, LAN Mode, PoE Mode


• Forwarding Rate:

  14.88 Mpps


• Switching Capacity:

  20 Gbps


• MAC Address Table Size:

  8K


• Jumbo Frame (FE, GE):

  10Kbytes


• Dimensions (LxWxH):



  • 240 x 105 x 27 mm


  • 9.45 x 4.13 x 1.06 in






• Weight:

  636 g (1.40 lb)


• Power Consumption:

  133.77W


• Power Dedicated to PoE+:

  110W


• Power Input:



  • 100–240V


  • 50–60 Hz


  • 2.2A






• Power Saving:

  EEE


• Operating Temperature:

  0 to 40°C (32 to 104°F)


• Storage Temperature:

  -20 to 70°C (-4 to 158°F)


• Operating Humidity:

  10 to 90% RH


• Storage Humidity:

  5 to 95% RH (non-condensing)

• Spanning Tree:

  IEEE 802.1d Spanning Tree, IEEE 802.1w Rapid Spanning Tree, IEEE 802.1s Multiple Spanning Trees (16 instances)


• Link Aggregation:

  IEEE 802.3ad LACP, up to 8 groups with up to 8 ports per group


• VLAN:

  Port-based and 802.1q VLANs, Management VLAN, Guest VLAN support


• Number of VLANs Supported:

  256 active VLANs (4,096 range)


• Auto Voice VLAN:

  Voice traffic is automatically assigned by OUI to a voice-specific VLAN and treated with appropriate levels


• IGMP Snooping:

  IGMP (v1/v2/v3) snooping provides for fast client joins and leaves of multicast streams and limits bandwidth-intensive video traffic to only the requestors; supports 256 multicast groups


• HOL Blocking Prevention:

  Head of line (HOL) blocking prevention


• Port Mirroring:

  Traffic on multiple ports (up to 3 ports) can be mirrored to another port for analysis with a network analyzer


• Security Features:



  • 802.1x Radius authentication


  • DHCP snooping


  • IP-MAC binding


  • Port Security (256 max entries per port)


  • DOS Attack Prevention


  • Port Isolation (Protected Ports)






• Storm Control:

  Support broadcast/unknown multicast/unknown unicast 16kbps~1000Mbps: in steps of 16kbps


• Quality Of Service:



  • 8 hardware queues


  • Strict, Weighted Round Robin (WRR)


  • Port-based, 802.1p priority-based, IPv4/v6 IP DSCP-based






• Access Control:

  Ingress, MC Based ACL, IPv4 Based ACL, IPv6 Based ACL, ACL Binding, Action: permit/deny


• RMON:

  Embedded remote monitoring (RMON 1, 2, 3, 9) software agent support for enhanced traffic management, monitoring, and analysis


• Management Interface:



  • HTTP


  • HTTPS






• Other Management:

  Telnet, SSH, DHCP client, system log, configuration upload and backup via HTTP or TFTP, PING, Traceroute, dual images, SNTP


• SNMP:



  • Version 1


  • Version 2c


  • Version 3






• Firmware Upgrade:

  Web Browser (HTTP/HTTPS)


• Rate Limiting:

  Rate limit according to network speed, 12kbps~1000Mbps: in steps of 16kbps


• Warranty and Support:



  • 5 Year Warranty (most countries)


  • 2 Year Warranty (Australia and New Zealand)
