WiFi Bands

• Tri-Band

*WiFi Speed

• 5,000+ Mbps

WiFi Technology

• WiFi 6E (802.11ax)

Wireless Radio Frequency

• 2.4GHz
• 5GHz
• 6GHz

Number of Radios

• Tri-Band

*Coverage

• 1,500 – 3,000 sq. ft.

Connected Devices

• 195+

Product Type

• Mesh WiFi System

Works With

• Linksys App

Router Type

• Mesh Router

Non-operating Temperature

• -20 °C to 60 °C

Dimensions (LxWxH)

• 95 x 95 x 196 mm

Wi-Fi Speed

• PHY rate up to 600 Mbps on 2.4GHz (2 spatial streams @ 40MHz channel width)
• PHY rate up 2400 Mbps (2 spatial streams @ 160MHz channel width) on 5GHz
• PHY rate up 2400 Mbps (2 spatial streams @ 160MHz channel width) on 6GHz

Operating Humidity

• 10% to 90% relative humidity and Non- Condensing

Operating Temperature

• 0-40 °C

Ports

• One (1) Gigabit (10/100/1000 Mbps) WAN port
• One (1) Gigabit (10/100/1000 Mbps) LAN port

Reset Button

• Ability to reset to factory default

Security Features

• Supports various wireless security/encryption types including WPA2/WPA3 Mixed Personal, WPA2 Personal, WPA3 Personal
• Parental Controls featuring time-based, domain-based and MAC address-based (device-based) blocking of Internet access
• Single-port and port-range forwarding, port triggering
• Network Address Translation (NAT)
• Stateful Packet Inspection (SPI) firewall

Wi-Fi Technology

• 802.11ax-Enhanced or AXE
• MU-MIMO (Multiple Input Multiple Output)
• DL-OFDMA (Orthogonal Frequency Division Multiple Access)
• TWT (Target Wake Time)
• STBC (Space Time Block Code)

Easy Setup

• Set up and access your network on the Linksys Mobile App, and easily prioritize connected devices as you need to.

Quality Of Service

• Quality of Service (QoS) is used to set up priority to specific devices, services or applications within the network through the router so that the maximum amount of available throughput and speed can be used.

Storage Temperature

• -20 °C to 60 °C

Processor

• 1 GHz dual core

Storage Humidity

• 10% to 90% Non-Condensing
