Part No
90NX05W1-M02M70

Sales Model Name
B9403CVAR-PP1649X

EAN Code


UPC Code


WEEE
0.739

BASE UNIT
VSNX05W1-BU2101




Operating System
Windows 11 Pro

Office
1-month trial for new Microsoft 365 customers. Credit card required.

LCD cover-material
Mg-Li

LCD cover-color
Star Black

Top case-material
Mg-Li

Top case-color
Star Black

Bottom case-material
Mg-Li

Bottom case-color
Star Black

Military grade
US MIL-STD 810H military-grade standard

Panel Size
14.0-inch

OLED
OLED

Brightness
400nits

Resolution
WQXGA+ (2880 x 1800) 16:10

Glare
Glossy display

Color gamut
DCI-P3: 100%

View angle(H/V)
178/178

Response time(Typ/Max) (ms)
1/1

Refresh rate
120Hz

Contrast  (Typ)
1000000:1

Touch Panel
Non-touch screen

Screen-to-body ratio
90 %

Pantone
Pantone Validated

IPS-level
Wide view

VESA CERTIFIED Display HDR
VESA CERTIFIED Display HDR True Black 600

Processor
Intel® Core 7 Processor 150U 1.8 GHz (12MB Cache, up to 5.4 GHz, 10 Cores)

Chipset
N/A

Discrete/Share
Share

Integrated GPU
Intel® Graphics

VRAM
N/A

How to upgrade memory
Not Available

Expansion Slot(includes used)
1x M. 2 2280 PCIe 4.0x4

On board memory
32GB LPDDR5X on board

Total System Memory
LPDDR5X 32GB

Storage
1TB M. 2 2280 NVMe PCIe® 4.0 Performance SSD

Front-facing camera
1080p FHD camera with IR function to support Windows HelloWith privacy shutter

On board Wireless
Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth® 5.4 Wireless Card

NumberPad
Support NumberPad

FingerPrint
FingerPrint

Keyboard type
Backlit Chiclet Keyboard

I/O ports
1x USB 3.2 Gen 2 Type-A2x Thunderbolt 4, compliant with USB4, supports display / power delivery1x micro HDMI (RJ45 lan)1x HDMI 2.1 TMDS1x 3.5mm Combo Audio Jack

Audio
Dolby AtmosSmart Amp TechnologyBuilt-in speakerBuilt-in array microphone

Battery
63WHrs, 3S1P, 3-cell Li-ion

AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal

Required charging power
Min: 55WMax: 65W*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher.

Dimension (WxHxD)
31.10 x 21.50 x 1.57 ~ 1.69 cm (12.24" x 8.46" x 0.62" ~ 0.67")

Weight (with Battery)
0.95 kg (2.09 lbs)

Weight (w/o Battery)
0.73 kg (1.61 lbs)

Security
Fingerprint sensorIR webcam with Windows Hello supportKensington Nano Security Slot(6x 2.5mm)BIOS setup user passwordHDD User Password Protection and SecuritySupport Absolute Persistence 2.0 (Computrace)Trusted Platform Module (TPM) 2.0NFC

Antivirus
McAfee® 1 year

MyASUS feature
System diagnosisBattery health chargingFan ProfileSplendidTru2LifeFunction key lockWiFi SmartConnectAppDealsLink to MyASUS

Built-in Apps
MyASUS

Disclaimer for Built-in Apps
Built-in Apps vary from OS SKU. *MyASUS/McAfee don"t support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)

Included in the Box
Micro HDMI to RJ45 gigabit ethernet adapterSleeve

Reparability Index (for Belgium)
9.4

Reparability Index (for France)
9.5

Ecolabels & Compliances
EPEAT Gold with Climate+Energy star 8.0FSC MixREACHRoHS

Base Warranty
3Y Pick up/ return

Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgradeACX13-007023NX//2Y Extension; 5Y OnSite Service(Next Business Day)*upgradeACX15-011800NX//3Y OnSite Service(Next Business Day); 3Y Accidental Damage Protection*; 3Y HDD_Retention*upgrade*If you would like to know the details, please contact your sales teams.

Battery warranty
Commercial NB B series Battery warranty follow system warranty, 4Y-5Y by WEP option.
