Integrated fixed device
Y

Dimensions without packaging (H x W x D)
Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 260.0 mm (1.72 in. x 17.40 in. x 10.24 in. ) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 267.0 mm (1.72 in. x 17.40 in. x 10.51 in. )

Dimensions with packaging (H x W x D)
90.0 mm x 555.0 mm x 400.0 mm (3.54 in. x 21.85 in. x 15.75 in. )

Chassis height
1

Installation type
Rack mounting, Desk mounting, Wall mounting

Weight without packaging
3.0 (6.61)

Weight with packaging
3.7 (8.16)

Typical power consumption
22.0

Typical heat dissipation
75.07

Maximum power consumption
Without PoE: 22.0 W Full PoE load: 160.0 W (PoE: 124 W)

Maximum heat dissipation
Without PoE: 75.07 Full PoE load: 545.94

Static power consumption
12.0

100% power consumption
22.0

MTBF
57.77

MTTR
2

Availability
>0.99999

Noise at normal temperature (acoustic power)
Noise-free (no fans), < 30

Noise at high temperature (acoustic power)
Noise-free (no fans), < 30

Noise at normal temperature (acoustic pressure)
Noise-free (no fans), < 20

Number of card slots
0

Number of power slots
0

Number of fans modules
0

Maximum number of physical ports on the entire device
18

Maximum number of 100GE ports
0

Maximum number of 40GE ports
0

Maximum number of 25GE ports
0

Maximum number of 10GE ports
0

Maximum number of 5GE ports
0

Maximum number of 2.5GE ports
0

Maximum number of GE ports
18

Maximum number of FE ports
18

Dedicated stack port
Not supported

Redundant power supply
Not supported

Long-term operating temperature
0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft. )

Restriction on the operating temperature variation rate
When the altitude is 1800-5000 m (5906-16404 ft. ), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft. ).

Storage temperature
–40°C to +70°C (–40°F to +158°F)

Long-term operating relative humidity
5% RH to 95% RH (non-condensing)

Long-term operating altitude
0–5000 m (0–16404 ft. )

Storage altitude
0-5000 m (0-16404 ft. )

Power supply mode
AC built-in

Rated input voltage
AC input: 100–240 V AC; 50/60 Hz

Input voltage range
AC input: 90 V AC to 300 V AC; 47 Hz to 63 Hz

Maximum input current
3 A

CPU
-

Memory
-

Flash memory
-

Console port
Not supported

Eth Management port
Not supported

USB
Not supported

Hardware real-time power detection
Not supported

Dying gasp
Not supported

RTC
Not supported

RPS input
Not supported

Complete device sleeping
Not supported

Service port surge protection
Common mode: ±4 kV

Power supply surge protection
Differential mode: ±6 kV; common mode: ±6 kV

Ingress protection level (dustproof/waterproof)
IP20

Types of fans
None

Heat dissipation mode
Natural heat dissipation

Airflow direction
-

PoE
Supported

Maximum PoE power consumption
124

PoE+ power interfaces
16

PoE++ power interfaces
-

Full load PoE power consumption 15.4W (802.3af)
8

Full load PoE power consumption 30W (802.3at)
4

Full load PoE++ power consumption 60W (802.3bt)
-

Full load PoE++ power consumption 90W (802.3bt)
-

Certification
EMC certification Safety certification Manufacturing certification
