Part No
90NX08C1-M003D0

Sales Model Name
P3605CVA-MB0100

EAN Code
4711387974063

UPC Code
197105974067

WEEE
1.343

BASE UNIT
VSNX08C1-BU0231

Operating System
Non-preinstalled OS

Office


LCD cover-material
Aluminum

LCD cover-color
Misty Grey

Top case-material
Aluminum

Top case-color
Misty Grey

Bottom case-material
Aluminum

Bottom case-color
Misty Grey

Military grade
US MIL-STD 810H military-grade standard

Panel Size
16.0-inch

Backlit
LED Backlit

Brightness
300nits

Resolution
WUXGA (1920 x 1200) 16:10

Glare
Anti-glare display

Color gamut
NTSC: 45%

View angle(H/V)
178/178

Response time(Typ/Max) (ms)
25/30

Refresh rate
60Hz

Contrast  (Typ)
1000:1

Touch Panel
Non-touch screen

Screen-to-body ratio


IPS-level
Wide view

Processor
Intel® Core i7-13620H Processor 2.4 GHz (24MB Cache, up to 4.9 GHz, 10 cores, 16 Threads)

Neural processor


Chipset
N/A

Discrete/Share
Share

Integrated GPU
Intel® UHD Graphics

VRAM
N/A

How to upgrade memory
Upgradable Need to remove bottom/top case

Expansion Slot(includes used)
2x DDR5 SO-DIMM slots1x M. 2 2230 PCIe 4.0x41x M. 2 2280 PCIe 4.0x4

DIMM Memory
16GB DDR5 SO-DIMM

Total System Memory
DDR5 16GB

Storage
1TB M. 2 2280 NVMe PCIe® 4.0 SSDSSD Housing for storage expansion

Front-facing camera
1080p FHD cameraWith privacy shutter

Wireless
Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5.4 Wireless Card

NumberPad
N/A

FingerPrint


Keyboard type
Backlit Chiclet Keyboard

I/O ports
2x USB 3.2 Gen 1 Type-A2x USB 3.2 Gen 2 Type-C support display / power delivery1x HDMI 2.1 TMDS1x 3.5mm Combo Audio Jack1x RJ45 Gigabit Ethernet

Audio
Audio by DiracSmart Amp TechnologyBuilt-in speakerBuilt-in array microphone

Battery
63WHrs, 3S1P, 3-cell Li-ion

AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal

Dimension (WxHxD)
35.84 x 25.39 x 1.79 ~ 1.80 cm (14.11" x 10.00" x 0.70" ~ 0.71")

Weight (with Battery)
1.78 kg (3.92 lbs)

Weight (w/o Battery)
1.56 kg (3.44 lbs)

Security
Fingerprint sensor integrated with Power KeyKensington Nano Security Slot(6x 2.5mm)McAfee® 30 days free trialBIOS Booting User Password ProtectionBIOS Integrity Measurement SupportBIOS Protection SupportBIOS Self RecoveryBIOS setup user passwordCSME BIOS Redundancy AssistanceEnhanced Password StrengthHDD User Password Protection and SecurityIntel CSME Firmware ResilienceIntel® BIOS GuardIntel® Boot GuardMicrosoft Secured-core PCMicrosoft Security Level 2Support Absolute Persistence 2.0 (Computrace)Trusted Platform Module (TPM) 2.0N/A

Antivirus


MyASUS feature
System diagnosisBattery health chargingFan ProfileSplendidTru2LifeFunction key lockWiFi SmartConnectAppDealsLink to MyASUS

Built-in Apps
MyASUSAI ExpertMeet (AI features need devices with 12GB RAM or more)

Disclaimer for Built-in Apps


Reparability Index (for France)
9.4

Ecolabels & Compliances
EPEAT Gold with Climate+Energy star 9.0FSC RecycledREACHRoHSTCO Certified

Base Warranty
3Y Pick up/ return

Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgradeACX13-007023NX//2Y Extension 5Y OnSite Service(Next Business Day)*upgradeACX14-017300NX//3Y HDD Retention*upgrade*If you would like to know the details, please contact your sales teams.

Battery warranty
Commercial NB P series Battery warranty follow system warranty.

Sustainable Material_Top cover(A part)
30% PCR recycled plastic(cover or inner frame)30% PIR recycled aluminum

Sustainable Material_Keyboard frame (C part)
30% PCR recycled plastic(cover or inner frame)30% PIR recycled aluminum

Sustainable Material_Bottom cover (D part)
30% PCR recycled plastic(cover or inner frame)30% PIR recycled aluminum

Sustainable Material_Battery
30% PCR recycled plastic

Sustainable Material_Keyboard
50% PIR recycled aluminum bracket

Sustainable Material_Speaker
45% PCR + 5% OBP PCR recycled plastic enclosure

Sustainable Material_Total PCR recycled plastic
