• Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
• Processor manufacturer: AMD
• Supported processor sockets: Socket AM5
• Processor socket: Socket AM5

• DirectX version: 12.0
• Maximum resolution: 4096 x 2160 pixels
• HDCP: Yes
• Parallel processing technology support: Not supported

• Motherboard chipset family: AMD
• Audio output channels: 7.1 channels
• Motherboard chipset: AMD X870
• Product colour: White
• Motherboard form factor: Micro ITX
• Audio chip: Realtek ALC4080
• Power source type: ATX
• PC health monitoring: Voltage, Temperature, Fan, Water cooling
• Component for: PC
• Windows operating systems supported: Windows 11 x64

• Maximum internal memory: 128 GB
• Unbuffered memory: Yes
• Supported memory clock speed (max): 8400 MHz
• Supported memory types: DDR5-SDRAM
• Memory slots type: DIMM
• Number of memory slots: 2
• Memory channels: Dual-channel
• ECC сompatibility: Non-ECC
• Maximum internal memory per slot: 64 GB
• Supported memory clock speeds: 5200, 8400, 8266, 4800, 6600, 7600, 7800, 5800, 6200, 6000, 7000, 8200 MHz, 8000, 4400, 7950, 7900, 6800, 5600 MHz, 7200, 7400, 6400

• Height: 35 mm
• Depth: 170 mm
• Width: 170 mm

• Wi-Fi standards: 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), 802.11b, Wi-Fi 4 (802.11n)
• Bluetooth version: 5.4
• Wi-Fi: Yes
• Ethernet interface type: 2.5 Gigabit Ethernet
• Ethernet LAN: Yes
• Top Wi-Fi standard: Wi-Fi 7 (802.11be)
• WLAN controller model: Realtek RTL8922AE
• LAN controller: Realtek RTL8125
• Bluetooth: Yes

• USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
• Number of SATA III connectors: 2
• USB 2.0 connectors: 1
• USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
• Number of chassis fan connectors: 1
• CPU fan connector: Yes
• Front panel connector: Yes
• EPS power connector (8-pin): Yes
• Front panel audio connector: Yes
• ATX Power connector (24-pin): Yes
• Chassis intrusion connector: Yes
• RGB LED pin header: Yes
• Number of EPS power connectors (8-pin): 1
• Number of CPU fan connectors: 2
• Number of water pump connectors: 1
• Number of RGB LED pin headers: 3

• System Management BIOS (SMBIOS) version: 2.7
• Desktop Management Interface (DMI) version: 2.7
• BIOS memory size: 256 Mbit
• Clear CMOS jumper: Yes
• BIOS type: UEFI AMI
• ACPI version: 5.0

• Package weight: 1.28 kg
• Package height: 95 mm
• Package width: 235 mm
• Package depth: 227 mm

• Antenna included: Yes
• Batteries included: Yes
• Screws included: Yes

• Supported storage drive interfaces: M. 2, SATA III
• Supported storage drive types: HDD & SSD
• Number of storage drives supported: 4
• RAID support: Yes
• RAID levels: 0, 1
• Number of HDDs supported: 2

• USB4 Gen 2x2 ports quantity: 1
• DisplayPort version: 1.4
• Headphone outputs: 1
• Line-in: Yes
• USB 2.0 ports quantity: 2
• HDMI version: 2.1
• USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
• WiFi-AP antenna jack: 2
• Ethernet LAN (RJ-45) ports: 1
• USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
• HDMI ports quantity: 1
• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2

• PCI Express x16 (Gen 5. x) slots: 1
• Number of M. 2 (M) slots: 2
• 2nd M. 2 highest PCI Express generation: 4.0
• 1st M. 2 largest key size: 2280
• 1st M. 2 highest PCI Express generation: 5.0
• 2nd M. 2 largest key size: 2280

• Battery weight: 3 g
• Number of battery cells: 1
• Battery type: CR2032
• Battery technology: Lithium-Manganese Dioxide (LiMnO2)
• Lithium weight per battery: 0.07 g

• Country of origin: Taiwan
• Products per shipping (inner) case: 1 pc(s)
