• Status: Launched
• Launch date: Q4'23
• Servicing status: Baseline Servicing

• Box: No
• Processor socket: LGA 1700
• Processor ARK ID: 236183
• Thermal Design Power (TDP): 80 W
• Processor manufacturer: Intel
• Processor family: Intel Xeon E
• Processor cache: 24 MB
• Processor threads: 16
• Processor operating modes: 64-bit
• Processor boost frequency: 5.2 GHz
• System bus rate: 16 GT/s
• Processor codename: Raptor Lake
• Processor cores: 8
• Processor base frequency: 2.8 GHz
• Processor model: E-2478
• Stepping: B0
• Maximum number of DMI lanes: 8
• Performance cores: 8

• Discrete graphics card: No
• On-board graphics card: No
• On-board graphics card model: Not available
• Discrete graphics card model: Not available

• Supported instruction sets: SSE4.2, AVX 2.0, SSE4.1
• Scalability: 1S
• Idle States: Yes
• Execute Disable Bit: Yes
• Market segment: Server
• Embedded options available: No
• CPU configuration (max): 1
• Thermal Monitoring Technologies: Yes
• Export Control Classification Number (ECCN): 5A992C
• Use conditions: Server/Enterprise
• PCI Express slots version: 5.0
• Maximum number of PCI Express lanes: 20
• PCI Express configurations: 1x16+1x4, 2x8+1x4
• Commodity Classification Automated Tracking System (CCATS): 740.17B1

• Maximum internal memory supported by processor: 128 GB
• Memory types supported by processor: DDR5-SDRAM
• ECC: Yes
• Memory channels: Dual-channel

• Intel VT-x with Extended Page Tables (EPT): Yes
• Intel® Boot Guard: Yes
• Intel Virtualization Technology (VT-x): Yes
• Mode-based Execute Control (MBE): Yes
• Intel® OS Guard: Yes
• Intel® Optane DC Persistent Memory Supported: No
• Intel Turbo Boost Max Technology 3.0: Yes
• Intel® Secure Key: Yes
• Intel 64: Yes
• Intel Trusted Execution Technology: Yes
• Intel Virtualization Technology for Directed I/O (VT-d): Yes
• Intel® Hyper Threading Technology (Intel® HT Technology): Yes
• Intel® AES New Instructions (Intel® AES-NI): Yes
• Intel® Turbo Boost Technology: 2.0
• Intel® Turbo Boost Max Technology 3.0 frequency: 5.2 GHz
• Intel® Turbo Boost Technology 2.0 frequency: 5.2 GHz
• Enhanced Intel SpeedStep Technology: Yes
• Intel® Total Memory Encryption - Multi Key: Yes
• Microprocessor PCIe Revision: Gen 5
• Intel® Transactional Synchronization Extensions: No
• Intel® Virtualization Technology with Redirect Protection (VT-rp): Yes
• Intel® Total Memory Encryption: Yes
