Part No
90NR0895-M00DK0

Model Name
G513RW-HQ113




EAN Code
4711081952497

UPC Code
195553952491




Marketing Name
ROG Strix G15

Color
Eclipse Gray

Dimension (W x D x H)
35.4 x 25.9 x 2.26 ~ 2.72 cm

Processor
AMD Ryzen 7 6800H Mobile Processor (8-core/16-thread, 20MB cache, up to 4.7 GHz max boost)

Weight
2.30 Kg

Chipset
N/A

Discrete/Optimus
MUX Switch + Optimus

Graphic
NVIDIA® GeForce RTX 3070 Ti Laptop GPU

Graphic Wattage
ROG Boost: 1460MHz* at 150W (1410MHz Boost Clock+50MHz OC, 125W+25W Dynamic Boost)

Graphic Memory
8GB GDDR6

IGPU
AMD Radeon Graphics

Panel Size
15.6-inch

Resolution
WQHD (2560 x 1440) 16:9

Refresh Rate
165Hz

Response Time (G2G)
3ms

Viewing Angle
170

Panel Tech
IPS-level

Brightness
300nits

Contrast
1:1000

DCI-P3 %
100.00%

Anti glare
anti-glare display

Adaptive-Sync technology
Adaptive-Sync

Pantone
N/A

Support Dolby Vision HDR
Yes

On board memory
N/A

Memory Slot
2x SO-DIMM slots

Total System Memory
8GB DDR5-4800 SO-DIMM *2

DIMM Memory
8GB DDR5-4800 SO-DIMM *2

Memory Max.
32GB

Multi-channel memory technology
Support dual channel memory

System Storage Installed
512GB PCIe® 4.0 NVMe M. 2 SSD

M. 2 slots support either SATA or NVMe
2

M. 2 SSD Support List
M. 2 512GB PCIe

M. 2 1TB PCIe

Expansion Slot (includes used)
2x DDR5 SO-DIMM slots

2x PCIe

On board Wireless
N/A

LAN
10/100/1000/2500 Mbps

Wi-Fi/Bluetooth
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth 5.2 (*BT version may change with OS version different. ) -RangeBoost

I/O Ports
1x RJ45 LAN port

1x USB 3.2 Gen 2 Type-C

1x USB 3.2 Gen 2 Type-C support DisplayPort / power delivery / G-SYNC

2x USB 3.2 Gen 1 Type-A

Display output
1x HDMI 2.0b

Audio
1x 3.5mm Combo Audio Jac k

Webcam
N/A

Mic
Built-in array microphone

Keyboard Type
Backlit Chiclet Keyboard Per-Key RGB

NumberPad
N/A

Aura Sync
Yes

Speakers
2-speaker system with Smart Amplifier Technology

Audio Tech
AI noise-canceling technology

Dolby Atmos

Hi-Res certification

Smart Amp Technology

Operating System
No preinstalled OS

Security
BIOS Administrator Password and User Password Protection

Trusted Platform Module (Firmware TPM)

Battery
90WHrs, 4S1P, 4-cell Li-ion

Power
o6.0, 280W AC Adapter, Output: 20V DC, 14A, 280W, Input: 100~240C AC 50/60Hz universal

Reparability Index (for FR)
7.3
