Sales Model Name
PM1503CDA-S70008

EAN Code


UPC Code


WEEE


BASE UNIT
VSNX09D1-BU1100

Operating System
Non-preinstalled OS

LCD cover-material
Plastic

LCD cover-color
Misty Grey

Top case-material
Plastic

Top case-color
Misty Grey

Bottom case-material
Plastic

Bottom case-color
Misty Grey

Military grade
US MIL-STD 810H military-grade standard

Panel Size
15.6-inch

Backlit
LED Backlit

Brightness
300nits

Resolution
FHD (1920 x 1080) 16:9

Glare
Anti-glare display

Color gamut
NTSC: 45%

View angle(H/V)
178/178

Response time(Typ/Max) (ms)
25/30

Refresh rate
60Hz

Contrast  (Typ)
700:1

Touch Panel
Non-touch screen

Screen-to-body ratio
87 %

IPS-level
Wide view

Processor
AMD Ryzen 5 7535HS Processor 3.3GHz (16MB Cache, up to 4.55 GHz, 6 cores, 12 Threads)

Neural processor


Chipset
N/A

Discrete/Share
Share

Integrated GPU
AMD Radeon Graphics

VRAM
N/A

How to upgrade memory
Upgradable Need to remove bottom/top case

Expansion Slot(includes used)
2x DDR5 SO-DIMM slots1x M. 2 2230 PCIe 4.0x41x M. 2 2280 PCIe 4.0x4

DIMM Memory
16GB DDR5 SO-DIMM

Total System Memory
DDR5 16GB

Storage
512GB M. 2 2280 NVMe PCIe® 4.0 SSDSSD Housing for storage expansion

Front-facing camera
720p HD cameraWith privacy shutter

Wireless
Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth® 5.4 Wireless Card

NumberPad
N/A

FingerPrint
FingerPrint

Keyboard type
Chiclet Keyboard with Num-key

I/O ports
2x USB 3.2 Gen 1 Type-A2x USB 3.2 Gen 2 Type-C support display / power delivery1x HDMI 1.4, up to 3840x2160p/30Hz1x 3.5mm Combo Audio Jack1x RJ45 Gigabit Ethernet

Audio
Audio by DiracBuilt-in speakerBuilt-in array microphone

Battery
50WHrs, 3S1P, 3-cell Li-ion

AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal

Required charging power


Dimension (WxHxD)
35.95 x 23.22 x 1.99 ~ 1.99 cm (14.15" x 9.14" x 0.78" ~ 0.78")

Weight (with Battery)
1.80 kg (3.97 lbs)

Weight (w/o Battery)
1.61 kg (3.55 lbs)

Security
Fingerprint sensor intergrated with TouchpadKensington Nano Security Slot(6x 2.5mm)BIOS Booting User Password ProtectionBIOS Integrity Measurement SupportBIOS Self RecoveryBIOS setup user passwordCSME BIOS Redundancy AssistanceEnhanced Password StrengthHDD User Password Protection and SecurityMicrosoft Security Level 2Support Absolute Persistence 2.0 (Computrace)Trusted Platform Module (TPM) 2.0N/A

MyASUS feature
System diagnosisBattery health chargingFan ProfileSplendidFunction key lockWiFi SmartConnectAppDealsLink to MyASUS

Built-in Apps
MyASUS

Disclaimer for Built-in Apps
Built-in Apps vary from OS SKU. *MyASUS/McAfee don"t support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)

Reparability Index (for France)
9.0

Ecolabels & Compliances
EPEAT Gold with Climate+Energy star 9.0FSC RecycledREACHRoHSTCO Certified

Base Warranty
3Y Pick up/ return

Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgradeACX13-007023NX//2Y Extension 5Y OnSite Service(Next Business Day)*upgradeACX15-011800NX//3Y OnSite Service(Next Business Day) 3Y Accidental Damage Protection* 3Y HDD_Retention*upgrade*If you would like to know the details, please contact your sales teams.

Battery warranty
Commercial NB P series Battery warranty follow system warranty.

Sustainable Material_Top cover(A part)
30% PCR recycled plastic(cover or inner frame)

Sustainable Material_Keyboard frame (C part)
30% PCR recycled plastic(cover or inner frame)

Sustainable Material_Bottom cover (D part)
30% PCR recycled plastic(cover or inner frame)

Sustainable Material_Battery
30% PCR recycled plastic

Sustainable Material_Keyboard


Sustainable Material_Speaker


Sustainable Material_Total PCR recycled plastic
29%
