Part No
90NX0801-M00680

Sales Model Name
B1503CVA-NJ0188

EAN Code


UPC Code


WEEE
1.43

BASE UNIT
VSNX0801-BUA121

Operating System
Non-preinstalled OS

Office


LCD cover-material
Plastic

LCD cover-color
Gentle Grey

Top case-material
Plastic

Top case-color
Gentle Grey

Bottom case-material
Plastic

Bottom case-color
Gentle Grey

Military grade
US MIL-STD 810H military-grade standard

Panel Size
15.6-inch

Backlit
LED Backlit

OLED


Brightness
250nits

Resolution
FHD (1920 x 1080) 16:9

Glare
Anti-glare display

Color gamut
NTSC: 45%

View angle(H/V)
90/60

Response time(Typ/Max) (ms)
12/16

Refresh rate
60Hz

Contrast  (Typ)
500:1

Touch Panel
Non-touch screen

Screen-to-body ratio
87 %

Pantone


IPS-level
TN

VESA CERTIFIED Display HDR


Processor
Intel® Core i7-1355U Processor 1.7GHz (12M Cache, up to 5GHz, 10 cores)

Neural processor


Chipset
N/A

Discrete/Share
Share

Integrated GPU
Intel® UHD Graphics

VRAM
N/A

How to upgrade memory
Upgradable Need to remove bottom/top case

Expansion Slot(includes used)
2x DDR5 SO-DIMM slots1x M. 2 2230 PCIe 4.0x41x M. 2 2280 PCIe 4.0x4

On board memory
N/A

DIMM Memory
16GB DDR5 SO-DIMM

Total System Memory
DDR5 16GB

Storage
1TB M. 2 2280 NVMe PCIe® 4.0 SSD

SSD Cache
N/A

Front-facing camera
720p HD cameraWith privacy shutter

Wireless
Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth® 5.3 Wireless Card

On board Wireless


WWAN


NumberPad
N/A

FingerPrint
FingerPrint

Keyboard type
Backlit Chiclet Keyboard with Num-key

I/O ports
2x USB 3.2 Gen 1 Type-A2x USB 3.2 Gen 2 Type-C support display / power delivery1x HDMI 1.4, up to 3840x2160p/30Hz1x 3.5mm Combo Audio Jack1x RJ45 Gigabit EthernetN/A

Audio
Audio by DiracBuilt-in speakerBuilt-in array microphone

Battery
42WHrs, 3S1P, 3-cell Li-ion

AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal

Dimension (WxHxD)
35.95 x 23.22 x 1.99 ~ 1.99 cm (14.15" x 9.14" x 0.78" ~ 0.78")

Weight (with Battery)
1.62 kg (3.57 lbs) // 42 WHrs battery

Weight (w/ 2nd Battery)
1.62 kg (3.57 lbs) // 50 WHrs battery

Weight (w/ 3rd Battery)


Weight (w/o Battery)
1.43 kg (3.15 lbs)

Security
Fingerprint sensor intergrated with TouchpadKensington Nano Security Slot(6x 2.5mm)BIOS Booting User Password ProtectionBIOS setup user passwordHDD User Password Protection and SecuritySupport Absolute Persistence 2.0 (Computrace)Trusted Platform Module (TPM) 2.0N/A

Antivirus


MyASUS feature
System diagnosisBattery health chargingFan ProfileSplendidTru2LifeFunction key lockWiFi SmartConnectAppDealsLink to MyASUS

Built-in Apps
MyASUS

Disclaimer for Built-in Apps
Built-in Apps vary from OS SKU. *MyASUS/McAfee don"t support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)

Included in the Box


Reparability Index (for France)
8.0

Ecolabels & Compliances
Energy star 8.0FSC MixREACHRoHSTCO Certified

Warranty
3Y PUR

Battery warranty
Commercial NB Battery warranty follow system warranty. * BP series Battery warranty 4Y-5Y by WEP option* Chromebook series Battery warranty 2Y-5Y by WEP option

Így is ismerheti: ExpertBook B 1 B 1503 CVA NJ 0188, ExpertBookB1B1503CVANJ0188, ExpertBook B1 B1503CVA NJ0188, ExpertBookB1B1503CVA-NJ0188, ExpertBook B1 B1503CVA-NJ 0188
