DISPLAY CHARACTERISTICS Design Op en Frame Diagonal 12.1", 31cm Panel IPS Technology Native resolution 1024 x 768 (0.8 megapixel) Aspect ratio 4:3 Panel brightness 540 cd/m2 Brightness 450 cd/m2 with touch Light transmittance 85% Static contrast 1000:1 Response time (BTB) 25ms Viewing zone horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89° Colour support 16.2mln (6bit + Hi-FRC) Horizontal Sync 31.4 - 60kHz Viewable area W x H 245.8 x 184.3mm, 9.7 x 7.2" Pixel pitch 0.24mm Bezel colour and finish blackTOUCH Touch technology projective capacitive Touch points 10 (HID, only with supported OS) Touch method finger, glove (latex), capacitive stylus Touch interface USB Supported operating systems All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. Through-Glass 6mm Palm rejection yesINTERFACES / CONNECTORS / CONTROLS Analog signal input VGA x1 Digital signal input HDMI x1
DisplayPort x1 Audio output Mini jack x1 HDCP yesFEATURES Extra anti-fingerprint coating, touch through-glass Glass thickness 3.15mm Glass hardness 7H 60950 Ball drop test yes Water and dust protection IP65 (front) OSD key lock yesGENERAL OSD languages EN, DE, FR, ES, IT, CN, JP Control buttons Menu, Scroll up / Brightness, Scroll down / Contrast, Select, Power User controls picture (contrast, brightness, H. position, V. position, phase, clock, auto adjust), advanced (colour temperature, sharpness), OSD (OSD timeout, OSD position, OSD H. position, OSD V. position, touch switch), option (reset, language, source select, display mode, factory) Plug&Play DDC2BM ECHANICAL Orientation lan dscape, portrait, face-up VESA mounting 100 x 100mm Operation temperature range (-°/+°) -20°C - 60°C Storage temperature range - 20°C - 60°CACCESSORIES INCLUDED Cables power, USB, HDMI, DP Guides quick start guide, safety guide Other AC adapter, external control pad Remote control external control padPOWER MANAGEMENT Power supply unit external Power supply DC 12 V Power usage 10W typical, 0.55W stand by, 0.5W off modeSUSTAINABILITY Regulations CE, EAC, RoHS support, ErP, WEEE, cULus, REACH Energy efficiency class (Regulation (EU) 2017/1369) FDIMENSIONS / WEIGHT Product dimensions W x H x D 308.5 x 248 x 41.5mm Box dimensions W x H x D 435 x 355 x 165mm Weight (without box) 2.1kg Weight (with box) 3.9kg EAN code 4948570118007COMPATIBLE ACCESSORIES Mounts/stands/bracket s OMK3-1RELATED INFORMATION Related products OMK3-1

Így is ismerheti: ProLite TF 1215 MC, ProLiteTF1215MC, ProLite TF1215 MC
