• Processor manufacturer: Intel
• Compatible processor series: Intel® Core i3, Intel® Core i7, Intel® Core i9, Intel® Pentium® Gold, Intel® Core i5, Intel® Celeron®
• Processor socket: LGA 1700
• Supported processor sockets: LGA 1700

• Maximum resolution: 4096 x 2304 pixels
• Parallel processing technology support: Not supported
• DirectX version: 12.0
• HDCP: Yes

• Motherboard chipset: Intel B760 Express
• Windows operating systems supported: Windows 11 x64, Windows 10 x64
• PC health monitoring: Water cooling, Voltage, Temperature, Fan
• Audio output channels: 7.1 channels
• Motherboard chipset family: Intel
• Motherboard form factor: ATX
• Product colour: Bronze

• Supported memory clock speed (max): 7600 MHz
• Supported memory clock speeds: 7000, 5800, 5400, 5600, 7200, 6800, 5200, 6400, 6600, 7600, 7400, 6200, 6000, 4000, 4800
• Memory channels: Dual-channel
• Memory slots type: DIMM
• Supported memory types: DDR5-SDRAM
• Unbuffered memory: Yes
• Number of memory slots: 4
• Maximum internal memory: 256 GB
• ECC сompatibility: ECC & Non-ECC

• Height: 35 mm
• Width: 305 mm
• Depth: 244 mm

• Wi-Fi standards: 802.11b, 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac)
• Wi-Fi: Yes
• Ethernet LAN: Yes
• Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
• Bluetooth version: 5.2
• WLAN controller model: Intel Wi-Fi 6E AX211
• Ethernet interface type: 2.5 Gigabit Ethernet
• Bluetooth: Yes

• Front panel connector: Yes
• S/PDIF out connector: Yes
• Number of SATA III connectors: 4
• CPU fan connector: Yes
• USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
• TPM connector: Yes
• Front panel audio connector: Yes
• ATX Power connector (24-pin): Yes
• RGB LED pin header: Yes
• EPS power connector (8-pin): Yes
• Total number of SATA connectors: 4
• Serial port headers: 1
• USB 2.0 connectors: 2
• USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
• 12V power connector: Yes

• Clear CMOS jumper: Yes
• Desktop Management Interface (DMI) version: 2.7
• BIOS type: UEFI AMI

• Package width: 335 mm
• Package weight: 19 kg
• Package depth: 270 mm
• Package height: 80 mm

• Cables included: SATA
• Batteries included: Yes

• Supported storage drive interfaces: M. 2, SATA III
• RAID levels: 10, 0, 1, 5
• Number of storage drives supported: 7
• Number of HDDs supported: 4
• Supported storage drive types: HDD & SSD
• RAID support: Yes

• WiFi-AP antenna jack: 2
• USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
• DisplayPort version: 1.2
• USB connector type: USB Type-C, USB Type-A
• Ethernet LAN (RJ-45) ports: 1
• Headphone outputs: 6
• HDMI version: 2.0
• USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
• HDMI ports quantity: 1
• DisplayPorts quantity: 1
• USB 2.0 ports quantity: 5
• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
• Microphone in: Yes

• PCI Express x16 (Gen 4. x) slots: 1
• Number of M. 2 (M) slots: 3
• 3rd M. 2 largest key size: 22110
• 3rd M. 2 highest PCI Express generation: 4.0
• 1st M. 2 highest PCI Express generation: 4.0
• 1st M. 2 largest key size: 22110
• 2nd M. 2 largest key size: 22110
• 2nd M. 2 highest PCI Express generation: 4.0

• Battery technology: Lithium-Manganese Dioxide (LiMnO2)
• Number of battery cells: 1
• Battery weight: 3 g
• Battery type: CR2032
• Lithium weight per battery: 0.07 g

• Country of origin: China
• Products per shipping (inner) case: 1 pc(s)
